This machine can perform Prevents Scum Risers, Wear-Preventive Coating, Prevents Heat Cracking, and Improvement of Holding power!

Compared to conventional machines, this machine has about half the dimensions and weight, half the heat generation, and twice the surface coating speed, and can be used with the same power supply voltage of AC100V!

For Press Dies！ Prevents Scum Risers!!

The vibration of the tip during use has been reduced, greatly reducing the impact on the cutting edge!

The amount of coating can now be more precisely controlled when using electrodes of φ1.0 or thinner!

The maximum coating height has been expanded from 30μm to 50μm!

The range of available clearances has been expanded!

For Die-cast Mold！Prevents Heat Cracking!!

Coating speed has been doubled and electrode consumption has been halved!

Easier and more extensive coating!

Coating thickness of up to 50 µm improves the life of the coated part!

The electrode’s heat generation is suppressed and its vibration is minimized, allowing it to be used for a longer period of time!

Features, Applications

As shown below, Depositron 720/820 can deposit hard metal such as tungsten carbide quickly and simply to all kinds of dies and cutters, machine parts , etc. to improve surface hardness up to HV1100. Electrode rod can be mounted up to φ0.3~3.0mm.
